核心技術規範 Technical Specification
- 材質 Material100% Nylon
- 塗層 CoatingPU Resin
- 工法 Construction梭織 (Woven)
- 熔點 Melting Point210°C
- 軟化點 Softening Point160°C
作業溫度Operating Temperature：-20°C ~ 120°C
物性標準 Physical Property Standard
| 項目 \ 單位 |
Hook
(鉤面) |
Napped Loop
(刷毛面) |
Unnapped Loop
(不刷毛面) |
Hook and Loop
Mixed-2(鉤毛同體) |
Soft Hook
(軟鉤) |
| 厚度 Thickness (mm) | ≧ 1.91 | ≧ 1.94 | ≧ 1.96 | ≧ 1.65 | ≧ 2.30 |
| 重量 Weight (g/cm²) | ≧ 0.031 | ≧ 0.036 | ≧ 0.031 | ≧ 0.026 | ≧ 0.026 |
| 密度 Density (條/in²) | ≧ 301 | ≧ 640 | ≧ 210 | ≧ 352 | ≧ 252 |
寬度規格與公差 Width & Tolerance
| 英吋 (Inch) | 公釐 (MM) | 公差範圍 (mm) |
|---|
| 3/8" | 10 | 9 - 11 |
| 3/4" | 20 | 19 - 21 |
| 5/8" | 16 | 15 - 17 |
| 1" | 25 | 24 - 26 |
| 1-1/4" | 32 | 31 - 33 |
| 1-1/2" | 38 | 37 - 39 |
| 英吋 (Inch) | 公釐 (MM) | 公差範圍 (mm) |
|---|
| 2" | 50 | 48 - 52 |
| 3" | 25 | 73 - 77 |
| 4" | 102 | 99 - 105 |
| 5" | 127 | 124 - 130 |
| 6" | 153 | 149 - 157 |
| 6.4" | 163 | Min. workable width: 156 (6.125") |
| 6.7" | 170 | Min. 170 |
疲勞測試 Lifecycle Performance
SHEARING ASTM-D5169:2021 PEELING ASTM-D5170:2021
| 產品組合 |
CYCLE |
0 |
2,000 |
5,000 |
10,000 |
| 橫向拉力 Shear | gf/cm² | 800 | 680 | 600 | 520 |
| 剝離拉力 Peel | gf/cm | 200 | 170 | 150 | 130 |
| 衰退率 degradation rate | % | | -15% | -25% | -35% |
| 橫向拉力 Shear | gf/cm² | 800 | 680 | 600 | 520 |
| 剝離拉力 Peel | gf/cm | 160 | 136 | 120 | 104 |
| 衰退率 degradation rate | % | | -15% | -25% | -35% |
| 橫向拉力 Shear | gf/cm² | 490 | - | 343 | - |
| 剝離拉力 Peel | gf/cm | 134 | - | 96 | - |
| 衰退率 degradation rate | % | | - | -30% | - |
| 橫向拉力 Shear | gf/cm² | 420 | - | 350 | - |
| 剝離拉力 Peel | gf/cm | 39 | - | 34 | - |
| 衰退率 degradation rate | % | | | -13% | |
| 產品組合 |
CYCLE |
0 |
1,000 |
2,000 |
3,000 |
| 橫向拉力 Shear | gf/cm² | 640 | 480 | 416 | 320 |
| 剝離拉力 Peel | gf/cm | 120 | 90 | 78 | 60 |
| 衰退率 degradation rate | % | | -25% | -35% | -50% |
洗滌與維護指南 Care Instructions
![[40°C 水洗]](https://lh3.googleusercontent.com/d/1bp5zBPuFg5BeagaeXoMVkBNpkqTRlCM0)
40°C 水洗
Wash at or below 40 °C (104 °F) (US, 2 dots, ●●)
![[不可漂白]](https://lh3.googleusercontent.com/d/1lR1bZ_RRdC-TgT6I-REL1EJuf6ZhoYy9)
不可漂白
Do not bleach
![[低溫烘乾]](https://lh3.googleusercontent.com/d/1yQAsLwzIkstQPRRH-EPLPZX-rRrGegvp)
低溫烘乾
Tumble drying (low temperature) maximum exhaust temperature 60°C(140 °F)
![[低溫熨燙]](https://lh3.googleusercontent.com/d/1yL2lM93Q5Np9uvlg9GK7fWUG9qyO3bWg)
低溫熨燙
The maximum temperature of the iron floor is 110°C (230 °F)
![[專業乾洗]](https://lh3.googleusercontent.com/d/1UrFl7JRlrEZt3FdBOgwHXHF5jK93RkZ0)
專業乾洗
Dry clean, tetrachloroethylene (PCE) only
耐色 Colour Fastness
| 測試項目 (Test Item) |
等級 (Ranking) |
測試方法 (Test Method) |
| 耐洗色牢度 Against Washing |
4 或以上 4 Or Superior |
AATCC-TM 61-2A-2013 / ISO 105 C06 B1M-2010 |
| 耐水色牢度 Against Water |
4 或以上 4 Or Superior |
AATCC-TM 107-2022 / ISO 105 E01-2013 |
| 耐汗色牢度 Against Sweat |
4 或以上 4 Or Superior |
AATCC-TM 15-2021 / ISO 105 E04-2013 |
| 耐摩擦色牢度 Against Rubbing |
4 或以上 4 Or Superior |
AATCC-TM 8-2016 / ISO 105 X12-2016 |
包裝與顏色 Packaging and color
-
標準顏色：共有 28 種顏色，包括黑色與白色。請參考 Lovetex 標準色卡。
Standard Colours: 28 colours including black and white. Please refer to Lovetex Standard Colour Card.
-
客製染色：可依需求提供。請提供樣品或 Pantone 色號。
Dye-to-match Colours: available upon requests. Please provide sample or pantone number.
-
包裝形式：每捲 25 公尺或碼；每捲 50 公尺或碼；大型 / 交叉繞線捲筒。特殊包裝形式可依需求提供。
Put-ups: 25 meters or yards per roll; 50 meters or yards per roll; Jumbo/ Crosswond spools. Special put-ups upon requests.
品質 Quality Compliance
![[ISO 9001]](https://lh3.googleusercontent.com/d/1ZVu8QeW0g2JCMWnIAKtvn7Bfha4F5zkP)
ISO 9001
![[OEKO-TEX]](https://lh3.googleusercontent.com/d/1BBUg0-IVbnLWqYiL-RObBDnRQ_Tqz8xT)
OEKO-TEX®
![[REACH]](https://lh3.googleusercontent.com/d/1DJrssQr1xeJLsfoDECsvdA72iV5qjRNU)
REACH
![[RoHS]](https://lh3.googleusercontent.com/d/1qx5dUv45Svj7_AxsvHBD76hfvOwg4rWV)
RoHS
